| Body | Dimensions | 157.6 x 74.1 x 7.8 mm (6.20 x 2.92 x 0.31 in) |
|---|---|---|
| Weight | 175 g / 198 g (ceramic) (6.17 oz) | |
| Build | Glass front (Gorilla Glass 6), glass back (Gorilla Glass 5), aluminum frame Glass front (Gorilla Glass 6), ceramic back, ceramic frame |
|
| SIM | Nano-SIM Nano-SIM + Nano-SIM |
|
| IP68 dust tight and water resistant (immersible up to 1.5m for 30 min) |
| Display | Type | Dynamic AMOLED, HDR10+ |
|---|---|---|
| Size | 6.4 inches, 103.8 cm2 (~88.9% screen-to-body ratio) | |
| Resolution | 1440 x 3040 pixels, 19:9 ratio (~522 ppi density) | |
| Protection | Corning Gorilla Glass 6 |
| Platform | OS | Android 9.0 (Pie), upgradable to Android 12, One UI 4.1 |
|---|---|---|
| Chipset | Exynos 9820 (8 nm) - EMEA/LATAM Qualcomm SM8150 Snapdragon 855 (7 nm) - USA/China |
|
| CPU | Octa-core (2x2.73 GHz Mongoose M4 & 2x2.31 GHz Cortex-A75 & 4x1.95 GHz Cortex-A55) - EMEA/LATAM Octa-core (1x2.84 GHz Kryo 485 & 3x2.42 GHz Kryo 485 & 4x1.78 GHz Kryo 485) - USA/China |
|
| GPU | Mali-G76 MP12 - EMEA/LATAM Adreno 640 - USA/China |
| Memory | Card slot | microSDXC (uses shared SIM slot) - dual SIM model only |
|---|---|---|
| Internal | 128GB 6GB RAM, 128GB 8GB RAM, 512GB 8GB RAM, 1TB 12GB RAM | |
| UFS 2.1 |
| Main Camera | Triple | 12 MP, f/1.5-2.4, 26mm (wide), 1/2.55", 1.4µm, dual pixel PDAF, OIS 12 MP, f/2.4, 52mm (telephoto), 1/3.6", 1.0µm, AF, OIS, 2x optical zoom 16 MP, f/2.2, 12mm (ultrawide), 1/3.1", 1.0µm, Super Steady video |
|---|---|---|
| Features | LED flash, auto-HDR, panorama | |
| Video | 4K@60fps (no EIS), 4K@30fps, 1080p@30/60/240fps, 720p@960fps, HDR10+, stereo sound rec., gyro-EIS & OIS |
| Selfie camera | Dual | 10 MP, f/1.9, 26mm (wide), 1/3", 1.22µm, dual pixel PDAF 8 MP, f/2.2, 22mm (wide), 1/4.0", 1.12µm, depth sensor |
|---|---|---|
| Features | HDR | |
| Video | 4K@30/60fps, 1080p@30fps |
| Sound | Loudspeaker | Yes, with stereo speakers |
|---|---|---|
| 3.5mm jack | Yes | |
| 32-bit/384kHz audio Tuned by AKG |
| Comms | WLAN | Wi-Fi 802.11 a/b/g/n/ac/6, dual-band, Wi-Fi Direct |
|---|---|---|
| Bluetooth | 5.0, A2DP, LE, aptX | |
| Positioning | GPS, GLONASS, BDS, GALILEO | |
| NFC | Yes | |
| Radio | FM radio (USA & Canada only) | |
| USB | USB Type-C 3.1, OTG, DisplayPort |
| Features | Sensors | Fingerprint (under display, ultrasonic), accelerometer, gyro, proximity, compass, barometer, heart rate, SpO2 |
|---|---|---|
| ANT+ Samsung DeX (desktop experience support) |
| Battery | Type | Li-Ion 4100 mAh, non-removable |
|---|---|---|
| Charging | 15W wired, PD2.0 15W wireless (Qi) 4.5W reverse wireless |
| Misc | Colors | Prism White, Prism Black, Prism Green, Prism Blue, Canary Yellow, Flamingo Pink, Ceramic Black, Ceramic White, Cardinal Red, Smoke Blue |
|---|---|---|
| Models | SM-G975F, SM-G975U, SM-G975W, SM-G975U1, SM-G9750, SM-G975N, SM-G975X, SC-05L | |
| SAR | 1.06 W/kg (head) 1.03 W/kg (body) | |
| SAR EU | 0.52 W/kg (head) 1.58 W/kg (body) |
